d1/d2(mm) |
L(mm) |
D(1mm) |
D2(mm) |
t1(mm) |
t2(mm) |
H(mm) |
PN10/IS0S-5/SDR11 |
|
|
weight(Kg) |
||||||||
|
25/20 |
68.5 |
34.8 |
29.9 |
18.4 |
16.1 |
31.9 |
0.04 |
|
|
32/20 |
79.5 |
43.0 |
29.9 |
20.0 |
16.1 |
40.0 |
0.05 |
|
|
32/25 |
79.5 |
43.0 |
35 |
20.0 |
18.0 |
40.0 |
0.06 |
|
|
40/20 |
89.9 |
53.0 |
29.7 |
21.7 |
16.1 |
44.8 |
0.08 |
|
|
40/25 |
90.5 |
53.2 |
35.3 |
21.7 |
18.0 |
46.8 |
0.08 |
|
|
40/32 |
91.0 |
53.0 |
43 |
21.5 |
19.0 |
45.0 |
0.10 |
|
|
50/20 |
110.0 |
65.4 |
39.5 |
25.0 |
16.0 |
50.0 |
0.16 |
|
|
50/25 |
110.0 |
65.5 |
35.3 |
25.0 |
18.0 |
51.0 |
0.16 |
|
|
50/32 |
107.0 |
65.0 |
43 |
24.0 |
19.0 |
52.5 |
0.17 |
|
|
50/40 |
107.0 |
65.0 |
53 |
24.5 |
21.0 |
52.5 |
0.17 |
|
|
63/25 |
128.6 |
80.3 |
25.5 |
28.6 |
17.6 |
65.0 |
0.27 |
|
|
63/32 |
128.6 |
80.5 |
43.4 |
28.6 |
19.1 |
64.5 |
0.27 |
|
|
63/40 |
128.6 |
80.5 |
53 |
28.6 |
21.5 |
64.5 |
0.28 |
|
|
63/50 |
128.6 |
80.5 |
65.4 |
28.6 |
24.0 |
64.6 |
0.28 |
|
|
75/32 |
144 |
92 |
43 |
31 |
18 |
65 |
0.40 |
|
|
75/40 |
144 |
92 |
53 |
30 |
21 |
65 |
0.40 |
|
|
90/25 |
184 |
112 |
36 |
35 |
19 |
76 |
0.70 |
|
|
90/50 |
185 |
112 |
65 |
35 |
26 |
80 |
0.80 |
|
|
110/50 |
207 |
132 |
65 |
40 |
26 |
90 |
1.00 |
|
